Ultra Isolation Transformers
The ultimate solution for critical applications requiring the cleanest possible power with maximum noise rejection and electrical isolation.
Superior performance for the most demanding applications
Our proprietary shielding design incorporates multiple layers of electrostatic and electromagnetic shielding for unparalleled noise rejection.
Exceptional common-mode noise rejection exceeding 100dB at 60Hz, significantly better than standard isolation transformers.
Special winding techniques minimize interwinding capacitance to reduce high-frequency noise coupling.
Ultra isolation transformers provide 10–100× better noise rejection compared to standard models.
Medical-grade ultra isolation transformers reduce leakage current to <5 μA for patient safety.
Superior rejection of fast transients and high-frequency noise components ensures clean power.
Maintains stable output voltage even under fluctuating input conditions for reliable performance.
Our medical ultra isolation transformers meet the stringent requirements of healthcare facilities and medical equipment manufacturers.
Where precision and reliability matter most
Critical for electron microscopes, mass spectrometers, and other sensitive analytical instruments that require ultra-clean power.
Protects sensitive RF equipment, base stations, and transmission systems from power line noise and interference.
Essential for wafer fabrication equipment, test systems, and cleanroom power distribution where even minor noise can cause defects.
Professional audio/video studios rely on ultra isolation to eliminate hum, buzz, and interference in high-end equipment.
Protects precision CNC machines, robotics, and measurement systems from electrical noise that can cause positioning errors.
Critical server and network equipment benefits from ultra-clean power to prevent data corruption and system crashes.
For healthcare applications
500VA to 10kVA
For research and precision instruments
300VA to 15kVA
For harsh environments
1kVA to 50kVA
Have questions or need a quote? Send us a message and we'll respond promptly.
KHAS-615,HALDAUNI Greater Noida,Gautam Budh Nagar 201306
| Input Voltage | 100V, 120V, 208V, 230V, 240V, 400V, 480V ±10% |
| Output Voltage | Same as input or custom configurations |
| Frequency | 50/60Hz ±5% |
| Isolation Voltage | Up to 4000V RMS |
| Common Mode Rejection | >100dB at 60Hz |
| Interwinding Capacitance | <10pF typical |
| Efficiency | 92-96% depending on size |
| Enclosure | NEMA 1, 12, 4X available |
| Cooling | Natural convection or fan cooled |
| Mounting | Floor standing, rack mount, wall mount options |
| Terminations | Terminal blocks, hardwired, or receptacles |
| Weight | Varies by capacity (5kg to 500kg) |
| Operating Temperature | 0°C to 40°C (standard), -20°C to 50°C (extended) |
| Storage Temperature | -40°C to 70°C |
| Humidity | 5% to 95% non-condensing |
| Altitude | Up to 3000m |
Multiple layers of copper shielding between windings prevent capacitive coupling of noise.
Precision wound cores using high-permeability silicon steel for optimal magnetic performance.
Primary, secondary, and inter-winding insulation systems for maximum safety.
Windings are vacuum impregnated with varnish to eliminate air pockets and reduce vibration.
Built-in thermal cutoffs and over-temperature protection for safety.
